Overall dimensions: 1.5” x 5” x 4.25” (38.1mm x 127mm x 108mm)
Devices contain no internal cooling fan
DO NOT stack devices on top of one another
When relying on convection cooling (with no additional cooling fans), for optimal performance across the full temperature range, allow for 2" of air gap on the top of the device and 1" from either of the sides.
For rack-mounted devices, if the unit is placed within a rack without the above stated minimum clearance requirements, it may be necessary to add cooling fans to the rack.
For mobile use in an application like a foam carrying case, to maintain proper cooling:
Minimum air gap of 2" required on top of devices for continuous operation
Minimum air gap of 2" required on both left and right sides of devices for continuous operation
